LED Turn signal mirrors

Is anyone familiar with wiring turnsignal mirrors? I just picked some M3 Sport mirrors up on eBay for 30 and i'm not quite sure how to wire them. Is there a "how-to" anywhere?
Reply With Quote
+ 0 -
Old 11-05-2005
rangererv's Avatar
I am: Evan m
Join Date: Mar 2005
Location: Dearborn Michigan
Vehicle: !!
Posts: 4,376
Total Props: 0
how to wire mirror mounting turn signals....

what you need:
Peterson yellow/ amber LED lights (part number= 168A)
you can buy thoes at walmart.

18 gauge wire.
i bought 30 feet and had about 5 left over.

if you have a sador gun that will work best to connect wires. If not, you need some connectors.

drill, wire cutters, electrical tape, ect.....(tools to cut and strip wires down)

what to do:

first start at the mirror.
you need to take the door pannel off and remove the mirror from the door.
drill a hole into the bottom of the mirror for the wires to go through. (the smaller the better for water purposes)
pull the wires up and out of the mirror between the mirror lens and the plactic.
connect a wire to each of the wires off the light.
run the wires through the same boot that the other stock wire runs through.
put screws into the lights to hold them to the mirror.
put mirror back on door.
find a ground and ground the white wire.
run the yellow wire down through the door pannel and through the boot that goes into the car.
punch a SMALL hole in the side of the boot and run wire through the front fender using a long stick and tape.
take headlights and side lights out completely.
find the wire in the fender and pull it out through the front.
*this is when the cutting of wires begin*

you need to cut the ground wire on the side/ parking light. the ground is BLACK.
connect the YELLOW wire to the BLACK wire THAT GOES TO THE LIGHT.
other other end of the black wire is just a ground that goes into the car. you can tape that and let it be.
connect a wire from the yellow wire that you JUST connected to the ground and connect that to the bottom GREEN AND WHITE wire on the MAIN turn signl. (it should be a green and white wire, but if not its the 2 colored wire. NOT brown or black one.

tape up all the wires nice and neat and put you truck back together.

I reccomend to check it before putting it back together.
And check the light that you bought before putting them on the mirror. To check, just put the yellow wire to the possitive of battery and white to negative.

hope you have fun and if you have ANY guestions, let me no.


SAS'd 2001 4x4 4.0L
3 in body lift.
SFA from 79 bronco d44 with 4in lift coils, l/s and 4.56
79 bronco 9in rear with 4:56 and detroit locker
35x12.5 G/Y wrangler mt/r, 15x8 M/T classic lock wheels
10k t-max winch with syth line, 150w k/c, waag bar
x2 programer, double/single rollbar, manual 1354

Reply With Quote
+ 0 -
Old 11-05-2005
rangererv's Avatar
I am: Evan m
Join Date: Mar 2005
Location: Dearborn Michigan
Vehicle: !!
Posts: 4,376
Total Props: 0
sry there are no pix of me doing it, but i think you will understand it... not hard.
i wrote that a while ago when i did mine, but let me no if you have any questions.
Reply With Quote
+ 0 -
Old 11-06-2005
Black 4x4's Avatar
I am: Len Krebs
Join Date: Sep 2005
Location: Minot, ND
Vehicle: 2001 Ford Ranger
Posts: 108
Total Props: 0
I had those on my 94 Ranger, did the same type of wiring job. I didn't like the fit, looked like a cheap mirror which it is. I traded off the 94 for a 2001 4x4.
Reply With Quote
+ 0 -
