Bent frame at bumper

Picked up this 2001 xlt for a good price,runs good but the bumper had taken a hit and was shifted over towards passenger side,after dropping the bump I was surprised to see that the frame ends had been bent,funny as the bumper did not even have a dent in it.The truck shakes pretty bad at over 50mph and the passenger side front frame rail has a small crease from being bent,the sway bar is making noise because the pillow bushings are out of line now,it appears to be a horizontal bend it did not get bent upwards or downwards,I'm thinking heat and and big hammer or chains/come along don't know as I've never had to bend a car/truck frame back into shape,I'm guessing I'd have to remove the sway bar and do both at the same time?kinda re enacting the hit in reverse?,what does everyone think??? any guesstimations what a shop might charge?
Attached Thumbnails
Bent frame at bumper-001.jpg   Bent frame at bumper-003.jpg   Bent frame at bumper-004.jpg   Bent frame at bumper-005.jpg   Bent frame at bumper-007.jpg

Bent frame at bumper-008.jpg   Bent frame at bumper-009.jpg
Reply With Quote
  #2
Old 05-01-2016
RF Veteran
iTrader: (1)

Join Date: Jan 2014
Location: Vancouver, BC
Posts: 7,577
The vibration at speed is concerning , could have a bit of crabbing going on.

And trying to re-straighten could make things worse.

If you have a flat level area, or go to a parking lot, lol, you can use a plum bob and tape to mark spots on the ground from various spots on the frame, then move truck and measure distances.

Bit of a "how-to" here: https://www.vintagepowerwagons.com/p...ts/15frame.pdf

Bumper could be new and frame already tweaked back via come along enough to sell it but not actually repaired.
Look around for other signs of possible repaired damage.

Frame straightening cost is based on time it takes, and that is based on how many directions frame has to be pulled and what disassembly is needed to do it.
It isn't "cheap" but really depends on value of vehicle, which may be why you got a good deal on this one.

4-wheel alignment is not too expensive, and that might tell you if frame is bent too much.
Reply With Quote
  #3
Old 05-01-2016
Member
Thread Starter

Join Date: Mar 2016
Location: glen burnie
Posts: 7
thanks for the info ron,It certainly needs the wheels aligned,I guess I'll do that and see how bad the vibration is then,I'm not looking for perfection,this is just going to be be a dump/errand runner,if it drives ok after an alignment I'll probably bend up some brackets to get the bumper to mount somewhat in line unless I can find someone to tweak the rails for $200 or so,the truck was bought from a company that was getting rid of some of the fleet,it was really cheap but my cap on it is $300 as far as getting work done.So if after an all wheel alignment if it drives ok-ish you think it's ok to bend back with a come along???
Reply With Quote
  #4
Old 05-01-2016
RF Veteran
iTrader: (1)

Join Date: Jan 2014
Location: Vancouver, BC
Posts: 7,577
Sure, if can be aligned.

Find a couple of trees and chain frame to one then come along to the other.
Don't use vehicles weight as the resistance or you can bend something else.

And always put a mat or something over chain and cable, if one "lets go" it can ruin your whole day.
