Mouintaineer OHC

i got one from a mountaineer, the bracket is smaller, wondering if it will fit. can post pics if need. from a 98 5.0L AWD
Reply With Quote
  #2
Old 07-31-2007
greygooseranger's Avatar
Member

Join Date: Apr 2006
Location: SE Michigan
Posts: 3,293
To in stall in your truck? It should be the same?! In any event, I wouldn't think it matters...
Reply With Quote
  #3
Old 07-31-2007
07Ranger's Avatar
Member
Thread Starter

Join Date: Mar 2007
Location: lima/dublin, ohio
Posts: 1,267
the actual OHC is a bit different, ill take pics for ya!
Reply With Quote
  #4
Old 07-31-2007
lifted97ranger's Avatar
Member

Join Date: Nov 2005
Location: Charlestown, IN
Posts: 1
pictures pictures pictures.....if it is out of a '02+, then the roof lines are different...
Reply With Quote
  #5
Old 07-31-2007
07Ranger's Avatar
Member
Thread Starter

Join Date: Mar 2007
Location: lima/dublin, ohio
Posts: 1,267
read first post, its out of an 98
Reply With Quote
  #6
Old 07-31-2007
lifted97ranger's Avatar
Member

Join Date: Nov 2005
Location: Charlestown, IN
Posts: 1
ahhhh blind

it should fit fine.....did you get a sunroof OHC?
Reply With Quote
  #7
Old 07-31-2007
07Ranger's Avatar
Member
Thread Starter

Join Date: Mar 2007
Location: lima/dublin, ohio
Posts: 1,267
heres the OHC
Name:  Picture030-1.jpg
Views: 1
Size:  76.1 KB
Name:  Picture031.jpg
Views: 1
Size:  33.6 KB
heres the harness for the OHC
Name:  Picture032-1.jpg
Views: 1
Size:  76.3 KB
Reply With Quote
  #8
Old 07-31-2007
07Ranger's Avatar
Member
Thread Starter

Join Date: Mar 2007
Location: lima/dublin, ohio
Posts: 1,267
Quote:
Originally Posted by lifted97ranger
ahhhh blind

it should fit fine.....did you get a sunroof OHC?
ya he had a sunroof
Reply With Quote
  #9
Old 07-31-2007
greygooseranger's Avatar
Member

Join Date: Apr 2006
Location: SE Michigan
Posts: 3,293
Thats the sunroof one... No biggie, it will fit fine....
Reply With Quote
  #10
Old 07-31-2007
lifted97ranger's Avatar
Member

Join Date: Nov 2005
Location: Charlestown, IN
Posts: 1
it is a sunroof OHC.....that is why the bracket is smaller.....it will take quite a bit more work to install this since the back of the bracket is held up by the headliner......if you don't use the headliner to hold it up, the back will have a gap in it and hang down....

it WILL fit with the headliner contours fine....

if i were you, i would sell this thing and get one from a Explorer/Mountaineer without a sunroof......
Reply With Quote
  #11
Old 07-31-2007
07Ranger's Avatar
Member
Thread Starter

Join Date: Mar 2007
Location: lima/dublin, ohio
Posts: 1,267
the bracket came right off the top frame! when removing it, it was 4 bolts from the top frame and it came right off!
Reply With Quote
  #12
Old 07-31-2007
lifted97ranger's Avatar
Member

Join Date: Nov 2005
Location: Charlestown, IN
Posts: 1
and
Reply With Quote
  #13
Old 07-31-2007
07Ranger's Avatar
Member
Thread Starter

Join Date: Mar 2007
Location: lima/dublin, ohio
Posts: 1,267
then y did u say its help up by the headliner? im confused
Reply With Quote
  #14
Old 07-31-2007
lifted97ranger's Avatar
Member

Join Date: Nov 2005
Location: Charlestown, IN
Posts: 1
if you look at the very BACK of the OHC, there is a little lip that slips up behind the headliner......the front part is held up by the bracket....THE FRONT PART ONLY.......in the picture you posted you can see the little black tab sticking out the back of he console....
Reply With Quote
  #15
Old 07-31-2007
07Ranger's Avatar
Member
Thread Starter

Join Date: Mar 2007
Location: lima/dublin, ohio
Posts: 1,267
ok i get it, thanks
Reply With Quote
  #16
Old 07-31-2007
5speedin2.3's Avatar
Member

Join Date: May 2005
Location: Livonia, Mi
Posts: 12
let me find the install pics of mine, i need to put it in the how-to, but if you would have searched for sunroof OHC im sure you would have found it.

found it.
https://www.ranger-forums.com/forum2...ht=sunroof+ohc
Reply With Quote
  #17
Old 07-31-2007
07Ranger's Avatar
Member
Thread Starter

Join Date: Mar 2007
Location: lima/dublin, ohio
Posts: 1,267
thanks a lot, thats exactly what i need!
Reply With Quote
  #18
Old 07-31-2007
5speedin2.3's Avatar
Member

Join Date: May 2005
Location: Livonia, Mi
Posts: 12
Quote:
Originally Posted by 07Ranger
thanks a lot, thats exactly what i need!
np man, btw you don't need that entire wiring harness, alot of that crap is for the sunroof.
