How would this look

Well everyone does the headlight mod... I was wondering how would it look to do a tail light mod on the 06 tails....

Pretty much Bake the red plastic off and paint black the chrome inside that is not necessary to the brake lights. Then reinstall the plastic...

I kinda want to try it but i dunno how it would look and I dont want to have to spend another 60 bucks on new tails if they turn out crappy.

Who else thinks it might look kinda cool?
Reply With Quote
  #2
Old 05-18-2010
Member

Join Date: Jul 2007
Location: NH
Posts: 292
I think someone has tried and the red lense does not come off as easy as the headlight lenses. I think the person who tried it had the lenses melt before the glue started to give.

Hopefully someone will speek up about it.
Reply With Quote
  #3
Old 05-18-2010
--weezl--'s Avatar
Member
iTrader: (1)

Join Date: Sep 2009
Location: Calgary AB, Canada
Posts: 3,139
it would look like the pre 04 corner markers that have been painted, doesn't look nearly as good as you think it would, plus, the reflectors help disperse the light rearward, and make them brighter, i think if you painted the inside, they would dim down and not be as bright.. which defeats the purpose of brake lights, personally, i'm trying to make my lights brighter...

if you did this on a set of lights like this.... it would be a different story, it doesn't really use the reflector, the chrome is for show...
Reply With Quote
  #4
Old 05-18-2010
powerranger262's Avatar
Member
iTrader: (1)

Join Date: Feb 2009
Location: Hartford, WI
Posts: 1,222
Look for a set, or one for that matter, on craigslist to try it on. I think it's a pretty cool idea. I get what you are saying about painting the stuff not needed for reflection, and I think that it would work. Try it dude.
Reply With Quote
  #5
Old 05-18-2010
btm757's Avatar
Member
Thread Starter
iTrader: (5)

Join Date: Jun 2009
Location: Norfolk / Chesapeake, VA
Posts: 3,980
Well im thinking tape off the reflector just like you do for the headlights
Reply With Quote
  #6
Old 05-18-2010
powerranger262's Avatar
Member
iTrader: (1)

Join Date: Feb 2009
Location: Hartford, WI
Posts: 1,222
Did you start yet?
Reply With Quote
  #7
Old 05-18-2010
powerranger262's Avatar
Member
iTrader: (1)

Join Date: Feb 2009
Location: Hartford, WI
Posts: 1,222
I want results.
Reply With Quote
  #8
Old 05-18-2010
--weezl--'s Avatar
Member
iTrader: (1)

Join Date: Sep 2009
Location: Calgary AB, Canada
Posts: 3,139
Quote:
Originally Posted by btm757 View Post
Well im thinking tape off the reflector just like you do for the headlights
yeah, except they are pretty much all reflector, like the 90's headlights
Reply With Quote
  #9
Old 05-19-2010
Machine090767's Avatar
RF Veteran

Join Date: May 2006
Location: Minnesota
Posts: 6,410
I don't see this mod working at all.
Reply With Quote
  #10
Old 05-19-2010
04blackedge's Avatar
RF Veteran
iTrader: (13)

Join Date: Jan 2007
Location: Durham, NC
Posts: 23,426
Let me link you to a mod someone did on f150online that came out good.
Reply With Quote
  #11
Old 05-19-2010
04blackedge's Avatar
RF Veteran
iTrader: (13)

Join Date: Jan 2007
Location: Durham, NC
Posts: 23,426
Long post, sorry!


Quote:
Originally Posted by DarrenWS6 View Post
This is my write up on '04 - '08 DIY Harley Davidson F150 tail lamps. Why spend $160.00 when the supplies cost $7.00? I also recorded video of the write up with a few helpful pointers, it is located at the end of this write up.

So basically everyone knows the 04+ Harley tails are a shade darker, except for the brake and reverse sections.


Heres how its done.

Begin my removing the tails which are held in my two 8mm bolts. Clean the back of the lights and mounting area while your back there. Maybe put some wax in too. Remove the bulbs carefully with the light upside down to prevent dust & debris from going inside.


Go inside and pre-heat your oven to 200 degrees. Put one light at a time in the oven on-top of a baking pan of some sorts as the heat of the oven grills will melt the plastic. Let them bake for 8 to 10 minutes. Once the reverse section starts looking foggy, take it out and work on the lens removal. Once its out of the oven the fog goes away.

Begin removing the lamp lens with a wide flathead driver, working from the bottom inner corner ( side that neighbors the tailgate ) and work your way up, once you make it to the top its smooth sailing for the other side. There will be some scary noises that sound like plastic is cracking, but its not. Use up and down motions to pull the lens away. DO NOT twist left and right, you will nick up the lens trim and it will be visible.




After the lens is removed, here is what your looking at.


Once you have the lens off, do not touch or clean the chrome shell too roughly as it will look smeared/smudged due to its a low quality reflective paint. The section that will be painted wont matter, but be cautious and gentle with the reverse and brake light sections. That area is your output glow.

After both lights lenses are removed, its time to get to masking. In my opinion, this was the toughest part because you need to use precision, make some excess tape cut offs, trim a lot of tape for cleaner fitment, and you need to be gentle while sticking the tape in the reverse and brake light sections as explained above, it may smudge, or lose some paint and leave a black spot. Use blue painters tape, or equal quality painting tape. A good tip is to kill some of EACH piece of tapes adhesion, by pressing it against your cotton shirt at least 3 times before sticking it in the lens. This lessens the chances of smudging or stripping the needed chrome, and leaves it with enough adhesion.

I started with the smallest ends first which are the East/West spots on reverse side, trimmed the tape as necessary, and filled in the center section. For the brake section, I did the longest ends North/South with brake side. I filled the center with 3 square tape pieces. This took me 45 minutes at a steady patient pace, and to go get a soda.





Next, I began sanding the remaining chrome very lightly with 2000 grit paper. Use finger tip strength only, and not alot of it. Just need to give it a nice brushed stainless look. Then clean the sanded areas off with a micro fiber cloth and prepare for painting.





I used the ever famous Krylon Fushion Satin Black. I was considering using Gloss Black, but I had more Satin Black at hand and i'm still going to smoke my lenses later down the road anyways. I did not use any adhesion promoter, or primer, I did the exact same process as I did on my fog lamps from 2008, which look fantastic still. Adhesives and primers are not necessary here. I did 3 light coats with no clear coat. I finished with a 4th coating, which I did heavier, in spot spraying motions to catch corners and jams that steady passes missed. Let them dry in the garage for an hour, and brought them inside to dry more since it rained outside and it got cold.

First pass.


Fourth final pass on one shell, the other chrome.


Both complete.


And for kicks, I put the lens carefully on one lamp to compare to a clear background lamp I already had. The reverse section only is whats painted in the project one. But the color compare shows very well here.



It began raining, so I didn't rush to get the lenses back on, so I let the shells dry in open air for three more hours. After that, I began carefully de-masking. This should be done slowly for the chromes finish to remain fine, and to not rip any paint from the edge. Here was the result.







After they are dry to the touch, its good to wipe them up gently with an MF cloth to remove some minor lint and paint haze. I had left over black sealant from when I did my fog lamps so I used that. Knead the tube and squeeze in a small thin amount of sealant into the crevasse section in the edges of the shells. Work with a patient pace of coarse as no not scratch your fresh paint, especially up on top, but know your product and know how fast it will dry.


After reinstalling the lenses to their shells, press down on them with enough force to tighten it down. There wont be any snap sounds or anything, but it will spread the sealant over the rim of the lens that inserts into the tail lamp, and will adhere properly. Using a utility strap is good personal insurance for tight adhesion for the lens. Leaving it wrapped tight for at a minimum of one hour. I have only two small straps for my fourwheeler, so I did one tail lamp at a time. I let them dry overnight, and in the morning I used some clear all purpose silicon on the outside corners only for a little more insurance. Do not squeeze silicon into the edge because it will fill in the section on the edge, and that will be visible.


The next morning, this is what all my work had resulted in.










So if you have 18 hours of spare time, and wont need your truck, and would like the Harley tail lamps, you can do it for about $7.00 vs $160.00. Its possible with headlamps, and its definitely possible with the tail lamps.







Lit up.




Faster shutter speed


They do appear darker than they look from the photos, but in direct sunlight all you can tell is the reverse section and a little of the upper brake portion is darker.

And here are two instructional videos I did of the process to capture technique, and methods.

Part 1.
YouTube - DIY Harley Davidson F150 taillamp mod Part 1

Part 2.
YouTube - DIY Harley Davidson F150 taillamp mod Part 2


This concludes my write up.
Reply With Quote
  #12
Old 05-19-2010
sullys_ranger's Avatar
Member

Join Date: Mar 2006
Location: NewLexington, Ohio
Posts: 3,615
almost not worth the effort, do the same thing with a light coat of nightshade
Reply With Quote
  #13
Old 05-19-2010
Silver's Avatar
Member

Join Date: Jun 2006
Location: edenton,nc
Posts: 2,708
I tried to on a old set i had lying around but the units would not come apart except in pieces lol... The way the lenses are seated in the bases at a angle all the way around making it imposable to separate
Reply With Quote
  #14
Old 05-19-2010
04blackedge's Avatar
RF Veteran
iTrader: (13)

Join Date: Jan 2007
Location: Durham, NC
Posts: 23,426
Quote:
Originally Posted by sullys_ranger View Post
almost not worth the effort, do the same thing with a light coat of nightshade
Except it looks so much better than 90% of the niteshaded tails on here.
Reply With Quote
  #15
Old 05-19-2010
btm757's Avatar
Member
Thread Starter
iTrader: (5)

Join Date: Jun 2009
Location: Norfolk / Chesapeake, VA
Posts: 3,980
I like... I need to go to the yard and see if I can find a set and give it a go... That is exactly what I was looking to do trent
Reply With Quote
  #16
Old 05-19-2010
Ford04Ranger4.0's Avatar
Member

Join Date: Dec 2008
Location: Plattsburgh, New York
Posts: 3,390
nice
Reply With Quote
  #17
Old 05-20-2010
--weezl--'s Avatar
Member
iTrader: (1)

Join Date: Sep 2009
Location: Calgary AB, Canada
Posts: 3,139
that f-150 mod looks wicked! i take back what i said
Reply With Quote
  #18
Old 05-20-2010
powerranger262's Avatar
Member
iTrader: (1)

Join Date: Feb 2009
Location: Hartford, WI
Posts: 1,222
Quote:
almost not worth the effort, do the same thing with a light coat of nightshade
No.
Reply With Quote
  #19
Old 06-17-2010
btm757's Avatar
Member
Thread Starter
iTrader: (5)

Join Date: Jun 2009
Location: Norfolk / Chesapeake, VA
Posts: 3,980
Hey If ive sealed my tail lights with bathroom silicone already do to moisture, puting them in the oven would it soften it up enough to separate the lens?
Reply With Quote
  #20
Old 06-17-2010
99offroadrngr's Avatar
TOYOTA
iTrader: (37)

Join Date: Jul 2007
Location: Massachusetts
Posts: 11,728
i would use a heat gun instead of oven just because you can go in small sections at a time. i used heat gun on corners and it worked way better imo but its your choice
Reply With Quote
  #21
Old 06-17-2010
WillInThe04Ranger's Avatar
Member

Join Date: Oct 2009
Location: Rocky Mount, NC
Posts: 666
Wow that f150 came out nice! I vote do it!
Reply With Quote
  #22
Old 06-21-2010
MikeDevo's Avatar
Member

Join Date: Jan 2009
Location: hatboro, PA
Posts: 489
you could do what i did and put a coat of night shade on and leave the reverse part clear. it looks good and if you don't put to many coats on then you'll have a real nice black cherry color to the lens. when i figure out how to post pictures ill post some up if ya want
