Welded the 9" up SOLID!!

not THE 9" in the truck.. but the spare one i had in the garage.

well i looked around a bit.. didn't really find much on the 9" being welded, PBB has way too much information for someone who sucks and key works in searching

anywho.. I started off by putting in a little 1 5/8" square piece of 12ga plate to keep the spatter from going down on the splines of the "bottom" side gear, then tacked the spiders to the bottom gear, then to the housing..

Name:  start.jpg
Views: 4
Size:  28.6 KB

Then using 6010 rods i welded the spiders to the bottom side gear. and welded the side gear to the housing, then started to fill up the bottom corners with weld.. slowlyyyyyy

then when it got close to the pins, i put the pins in.

Name:  middleish.jpg
Views: 5
Size:  24.7 KB

**skip forward like 3 hours and a few dozen 6010 rods**

Name:  beef.jpg
Views: 7
Size:  31.8 KB

Stolen from Smakes

Name:  324282904_9b2dd553ff.jpg
Views: 4
Size:  39.7 KB

Then cleaned it up real pretty with the wire wheel.. and welded on the top side gear. I'm not done yet, i'm going to weld the rest of it up, just ran out of time.. And yes, i know i didn't have to weld the side gear on.. but why not

Name:  almostdone.jpg
Views: 7
Size:  28.9 KB

Lets just say, if it breaks.. its gonna be cool Now all i need to do is finish welding it, file the stubborn splatter off then setup the used 5.13s i have.

Last edited by 99ranger4x4; 07-16-2009 at 11:17 PM.
Reply With Quote
  #2
Old 07-16-2009
Ray_Welder's Avatar
Member

Join Date: Jan 2008
Location: Zephyrhills, FLorida
Posts: 1,037
Holy crap, got enough weld there ?
Reply With Quote
  #3
Old 07-16-2009
99ranger4x4's Avatar
RF Veteran
Thread Starter
iTrader: (3)

Join Date: Jun 2006
Location: Austin, TX
Posts: 12,198
Quote:
Originally Posted by Ray_Welder View Post
Holy crap, got enough weld there ?
i didn't want it breaking
Reply With Quote
  #4
Old 07-16-2009
timpat92855's Avatar
Member
iTrader: (1)

Join Date: Nov 2006
Location: Lousiville, MS
Posts: 1,067
Looks like something else will break before that does.
Reply With Quote
  #5
Old 07-16-2009
99ranger4x4's Avatar
RF Veteran
Thread Starter
iTrader: (3)

Join Date: Jun 2006
Location: Austin, TX
Posts: 12,198
like my bastard 1310-1330 u joint? lol

I need to buy a 1330 yoke for that 9" before i go wheelin again..


on a side note
10,000 POST CLUB!!!!! WOOOOOO
Reply With Quote
  #6
Old 07-16-2009
zabeard's Avatar
who?
iTrader: (8)

Join Date: Nov 2004
Location: IN
Posts: 26,045
well that wont slip any more! lol
Reply With Quote
  #7
Old 07-17-2009
camodown's Avatar
Lost in Nowhere
iTrader: (3)

Join Date: Feb 2007
Location: Midland, TX
Posts: 5,029
damn, you are locked for sure
Reply With Quote
  #8
Old 07-17-2009
99ranger4x4's Avatar
RF Veteran
Thread Starter
iTrader: (3)

Join Date: Jun 2006
Location: Austin, TX
Posts: 12,198
in theory

Last edited by 99ranger4x4; 07-17-2009 at 12:15 AM.
Reply With Quote
  #9
Old 07-17-2009
korey89's Avatar
Member
iTrader: (2)

Join Date: Mar 2008
Location: South, FL
Posts: 4,672
I did the same thing to my front diff. Way to be a copycat, jeeze...


Looks strong lol
Reply With Quote
  #10
Old 07-17-2009
Member

Join Date: Apr 2007
Location: Mission Hills, California
Posts: 798
add like 30 lbs to it? lol...... nice work
Reply With Quote
  #11
Old 07-17-2009
99ranger4x4's Avatar
RF Veteran
Thread Starter
iTrader: (3)

Join Date: Jun 2006
Location: Austin, TX
Posts: 12,198
hopefully i'll bring it home tuesday. I didn't dare quench it and it was still WAY too hot to put in the plastic container in the back of my moms car haha

I'll weigh it and weigh my buddies before i weld it too.
Reply With Quote
