truck cap size

I want to get a cheap truck cap just for when I go camping. I am starting to look around on craigslist. What size do I need, I found alot of caps for tacomas, will those fit? One of them ays the dimensions, 6'3" x 5'. What is the size of my bed? 4x4 edge ext cab
Reply With Quote
  #2
Old 04-05-2009
rizoss16's Avatar
Member
Thread Starter

Join Date: Nov 2008
Location: CT
Posts: 808
Reply With Quote
  #3
Old 04-05-2009
ClemsonRanger03's Avatar
Member
iTrader: (1)

Join Date: Mar 2009
Location: Clemson, SC
Posts: 804
Our beds, or most, are 6ft beds so that sounds almost like the right dimensions. I know mine is a leer and I have seen the exact camper on tacomas, new and old. Most companies try to standardize the sizes.
Reply With Quote
  #4
Old 04-05-2009
Jimmeh's Avatar
Member
iTrader: (1)

Join Date: Dec 2007
Location: Columbia Falls, MT
Posts: 3,224
Here is my how to on measuring your bed.

First, you will need a tape measure:

Name:  Picture185.jpg
Views: 1832
Size:  176.4 KB

Then, what you do (PAY ATTENTION TO THIS) is take the tang of the tape (the flat part that is kind of like a ..... what are those called? Oh yeah, HOOKS!), and......HOOK it to the cab side of the bed, as shown:

Name:  Picture186.jpg
Views: 1862
Size:  64.0 KB

Then, what you do, is keep the big part in your hand, and pull it to the end of the bed. And guess what's cool about tape measures? They have numbers on them, telling you how long something is in inches (don't worry so much about those small lines, as I don't want to confuse you, just pay attention to the numbers). And guess what? It looks as if Ranger beds are 75 inches long, which is, I think, 6'3".

Name:  Picture187.jpg
Views: 3067
Size:  72.3 KB

Now, the next part is kind of tricky, but just as simple as this. What you do is measure the WIDTH of the bed. Again, all you have to do is hook the tang (or the hook) of the tape on one side, and pull the big part to the other. And guess what? It looks as if Ranger beds are 5 foot wide!

Name:  Picture188.jpg
Views: 3469
Size:  51.0 KB

I hope that helped. It was extremely difficult, as tape measures are heavy, and VERY SHARP!

Name:  Picture189.jpg
Views: 1831
Size:  291.0 KB
Reply With Quote
  #5
Old 04-05-2009
Dustin S's Avatar
Member

Join Date: Nov 2007
Location: trenton,GA
Posts: 724
^^ very well done mr. jimerson
Reply With Quote
  #6
Old 04-05-2009
mossyoak03's Avatar
Member
iTrader: (1)

Join Date: Oct 2006
Location: Virginia Beach, VA
Posts: 193
hahah you should submit that as a how-to james paul
Reply With Quote
  #7
Old 04-05-2009
rizoss16's Avatar
Member
Thread Starter

Join Date: Nov 2008
Location: CT
Posts: 808
LMAO!!!! thanks man! now I'll know for next time, should go in to the how to section. lol it is dark out and I didn't feel like getting off my ***
Reply With Quote
  #8
Old 04-05-2009
Trigger01's Avatar
RF Veteran
iTrader: (2)

Join Date: Oct 2005
Location: Knoxville, TN
Posts: 18,788
Seriously, just get one made for a Ranger. It'll look a lot better than something made for a Tacoma, just be patient, one will pop up sooner or later.
Reply With Quote
  #9
Old 04-05-2009
Jimmeh's Avatar
Member
iTrader: (1)

Join Date: Dec 2007
Location: Columbia Falls, MT
Posts: 3,224
Quote:
Originally Posted by Trigger01 View Post
Seriously, just get one made for a Ranger. It'll look a lot better than something made for a Tacoma, just be patient, one will pop up sooner or later.
The ones for Tacoma's aren't that much different then a Ranger one. They have a very similar design, but the tops just touch the cab.

I agree, though, I would just save up and get one for a Ranger. If anything, go to your local topper dealers, and see what they have for used ones.
Reply With Quote
  #10
Old 04-06-2009
Hitch's Avatar
Member

Join Date: Nov 2006
Location: OH
Posts: 401
I hope this helps anyone that has questions:




These are Factory Dimensions from the truck manufactures.
Bed Measurements are measured on the floor of the bed, NOT the bed rails.
Width is measured on the floor at the rear of the bed.
Cab Height is measured from bed rail to highest point on cab.
All measurements are in inches.



GM
07- 08 New Body LENGTH WIDTH CAB HEIGTH
Chevy XS 69.3" 62.5" 22.6"
Chevy SB 78.7" 62.5" 22.6"
Chevy LB 97.6" 62.5" 22.6"
Dually LB 97.6" 62.5" 22.6"
1999-2007
Chevy XS 68.5" 60.2" 22.2"
Chevy SB 78.6" 64.8" 22.2"
Chevy LB 97.6" 64.8" 22.2"
Chevy SS 78.6" 49.1" 22.2"
Dually LB 97.6" 64.8" 22.2"
07- 08 New Body
GMC XS 69.3" 62.5" 22.6"
GMC SB 78.7" 62.5" 22.6"
GMC LB 97.6" 62.5" 22.6"
Dually LB 97.6" 62.5" 22.6"
1999-2007
GMC XS 68.5" 60.2" 22.2"
GMC SB 78.6" 64.8" 22.2"
GMC LB 97.6" 64.8" 22.2"
GMC SS 78.6" 49.1" 22.2"
Dually LB 97.6" 64.8" 22.2"
2004-2008
Col/Cay XS 61.1" 57.2" 20.5"
Col/Cay SB 72.8" 57.2" 20.5"


Dodge
2002-2008 LENGTH WIDTH CAB HEIGTH
Dodge SB 75.9" 66.4" 23.5"
Dodge LB 98.3" 66.4" 23.5"
Dually LB 98.3" 66.4" 23.5"
2005-2008
Dakota XS 64.9" 59.6" 20.2"
BED SPECIFICATION AND CAB HEIGHT
1/7/2008 1
Dakota SB 78.8" 59.6" 20.2"


Ford
2004-2008
F-150 LENGTH WIDTH CAB HEIGTH
Ford XS 67.0" 64.2" 21.5"
Ford SB 78.8" 64.2" 21.5"
Ford LB 97.4" 64.2" 21.5"
Ford FS 78.8" 53.5" 21.5"
08 Super Duty
Ford SB 81.8" 69.3" 25.3"
Ford LB 98.0" 69.3" 25.3"
Dually LB 98.0" 69.3" 25.3"
1999-2007
Super Duty
Ford SB 82.4" 65.5" 25.2"
Ford LB 96.6" 65.5" 25.2"
Dually LB 96.6" 65.5" 25.2"
1993-2008
Ranger SB 72.8" 52.0" 20.7"
Ranger LB 84.6" 52.0" 20.7"
Ranger SS 72.8" 47.5" 20.7"


Mazda
1998-2008 LENGTH WIDTH CAB HEIGTH
Mazda SB 71.8" 52.0" 20.7"


Toyota
07 - 08 New Body LENGTH WIDTH CAB HEIGTH
Tundra XS 66.7" 66.5" 22.8"
Tundra SB 78.7" 66.4" 22.9"
Tundra LB 97.6" 66.4" 22.9"
2002-2007
Tundra XS Dual Cab 74.0" 63.3" 21.5"
Tundra SB Ex Cab 74.8" 62.8" 21.5"
Tundra LB 98.2" 62.8" 21.5"
Tundra SS 74.8" 53.8" 21.5"
2005-2008
Tacoma XS 60.3" 56.7" 20.0"
Tacoma SB 73.5" 56.7" 20.0"


Nissan LENGTH WIDTH CAB HEIGTH
2005-2008
Titan XS 67.1" 63.8" 22.2"
Titian SB 78.9" 63.8" 22.2"
2008 New Beds
Titan New SB 87.2" 63.8" 22.2"
Titan New LB 99.1" 63.8" 22.2"
1/7/2008 2
2005-2008
Frontier XS 59.5" 61.4" 20.7"
Frontier SB 73.3" 61.4" 20.7"
New for 07
Frontier DC SB 73.3" 61.4" 20.7"


Mitsubishi LENGTH WIDTH CAB HEIGTH
2006-2008
Raider XS 64.9" 59.6" 20.2"
Raider SB 78.8" 59.6" 20.2"


Isuzu
2006-2008
I-280 SB 72.8" 57.2" 20.5"
I-350 XS 61.1" 57.2" 20.5"
1/7/2008 3
1/7/2008 4
1/7/2008 5
1/7/2008 6
Reply With Quote
  #11
Old 04-06-2009
rizoss16's Avatar
Member
Thread Starter

Join Date: Nov 2008
Location: CT
Posts: 808
I found this:
http://newlondon.craigslist.org/pts/1077971964.html
$100 sound decent? My truck is red so it would look stupid, is fiberglass hard to paint? I think that bump on top would look wierd though, if anyone has seen a pic of a ranger somewhere with a cap like that that rises please post.
Reply With Quote
  #12
Old 04-06-2009
rizoss16's Avatar
Member
Thread Starter

Join Date: Nov 2008
Location: CT
Posts: 808
Also, is it possible to have on the cap AND the bed liner? or do I have to take out the bed liner each time I use the cap?
Reply With Quote
  #13
Old 04-06-2009
FullThrottle02's Avatar
Member
iTrader: (3)

Join Date: Apr 2008
Location: McHenry,IL
Posts: 586
You can leave the bedliner in with the cap. I was also looking for one and was advised to look for one off of a 98' or new ranger so the cap lines up with the cab right. If you get an older one it won't look right, it would still fit ok though.
Reply With Quote
  #14
Old 04-06-2009
rizoss16's Avatar
Member
Thread Starter

Join Date: Nov 2008
Location: CT
Posts: 808
I found one made for a ranger, it is gloss black, flat top, sliding windows, it is nice, if it wasn't for the giant hole! lol, there is a hole in the rear left side about 5" wide by 10" tall, looks like someone hit it with a sludge hammer. It is fiberglass, I can get this for cheap, if Its possible to fix that hole I will take it since the rest of it is nice, shiny paint too! So is it possible to fix? how would I do it?
Reply With Quote
  #15
Old 04-06-2009
Melt's Avatar
Member
iTrader: (1)

Join Date: Apr 2008
Location: Denver, CO
Posts: 3,392
Quote:
Originally Posted by rizoss16 View Post
Also, is it possible to have on the cap AND the bed liner? or do I have to take out the bed liner each time I use the cap?
if your bedliner is over the rail you will have to cut it in order to use the c - clams ... or you can be like this dumbass i knew in wisconsin that had his entire shell held down with DECK SCREWS
Reply With Quote
  #16
Old 04-06-2009
Trigger01's Avatar
RF Veteran
iTrader: (2)

Join Date: Oct 2005
Location: Knoxville, TN
Posts: 18,788
The cap you posted is ugly as sin and would look even worse on your truck seeings as you have a newer truck and that thing is older than Methuselah.
Reply With Quote
  #17
Old 04-06-2009
Trigger01's Avatar
RF Veteran
iTrader: (2)

Join Date: Oct 2005
Location: Knoxville, TN
Posts: 18,788
Quote:
Originally Posted by Melt View Post
if your bedliner is over the rail you will have to cut it in order to use the c - clams ... or you can be like this dumbass i knew in wisconsin that had his entire shell held down with DECK SCREWS
Mine was kinda done the same way before I got it. There are screw holes all the way down the sides.
