HID Fog Questions

Okay so as a few of you know i recently converted my headlights to 6000k HID.. which was the GREATEST thing ever.

Now I want to do my fogs to 3000k so i get the blue and yellow look like FX4wannabe01 has done and some others i am sure..

What i want to is this:

Is it straight plug and play like the headlights?

Will my stock switch properly power them?

Are they any precautions i should take or things i should look into first?

Any help or advice is greatly appreciated.
Reply With Quote
  #2
Old 10-09-2008
Fx4wannabe01's Avatar
RF Veteran
iTrader: (23)

Join Date: May 2005
Location: Boring, Oregon
Posts: 21,721
Stright up plug and play. Should be. you know how the stock headlamp plugs plug into a set of wires which go to the ballast? Well that connection will likely have to be cut and butt connected/crimped together for the fogs. The stock plug and the hid plug will not work together. One has 1/4" spades and the other has round or flat small tiny spades....plus the housing that the spades are in do not work together. At least that's how my kit was like.

No problems with powering them.

Find 9145 bulbs. Direct swap into your housing. 9005's fit, but not that well, and well...to be honest, it's a pain to make the 9005's fit.



Once again...left the camera in my work locker, so no pics for now. Still...keep an eye out for my bump of the hid how-to thread...likely tomorrow morning afterwork.
Reply With Quote
  #3
Old 10-09-2008
jaycheetwood's Avatar
Member
Thread Starter

Join Date: Sep 2008
Location: Ogden, Utah
Posts: 2,218
Sweet yeah pics regarding this would be awesome!! :

"Well that connection will likely have to be cut and butt connected/crimped together for the fogs. The stock plug and the hid plug will not work together. One has 1/4" spades and the other has round or flat small tiny spades....plus the housing that the spades are in do not work together. At least that's how my kit was like."

I would also like to know ballast mount points that would be awesome.

I appreciate. I think the blue/yellow look you have is amazing.
Reply With Quote
  #4
Old 10-09-2008
Fx4wannabe01's Avatar
RF Veteran
iTrader: (23)

Join Date: May 2005
Location: Boring, Oregon
Posts: 21,721
haha..thanks man. it sorta matches my truck. lol.

here's a teaser of my buddy trevor's truck...also 3000k fogs..and the truck kinda looks like yours kinda...
Name:  P5310212.jpg
Views: 2
Size:  69.7 KB
Reply With Quote
  #5
Old 10-09-2008
jaycheetwood's Avatar
Member
Thread Starter

Join Date: Sep 2008
Location: Ogden, Utah
Posts: 2,218
Yeah thats what i am after.. ohhhh the jealousy of his lift haha.
