How To: Eliminate Door Dinger on 04+

I got tired of listening to that freaking ding everytime I opened my door when I was modding and had the radio on so I set off on finding a way to turn it off. This will totally eliminate the door dinger when the key is in the ignition, I choose to put it on a switch so I can turn it on and off whenever I want.

I got this mod off of www.generation-edge.info but I figured it would help this site as well. All the pictures are mine though, credit to Diggr for doing the research originally.

Tools needed:
Torx 15
8mm socket
Wire cutters/strippers
SPST switch (optional)
and your connectors of choice

You'll need to remove the under the dash panel, here is Ford's manual instructions on how to do it with my own pics under that. The cover is held on with 4 Torx screws. 2 behind the parking brake handle and then 2 on both bottom corners. The metal panel behind that is help on by 5 8mm bolts.

Name:  manual1.jpg
Views: 29
Size:  66.9 KB

Name:  manual2.jpg
Views: 33
Size:  70.6 KB

Name:  manual3.jpg
Views: 29
Size:  91.8 KB

Name:  normal.jpg
Views: 29
Size:  54.9 KB

Name:  torx1.jpg
Views: 27
Size:  58.3 KB

Name:  torx2.jpg
Views: 27
Size:  62.8 KB

Name:  torx3.jpg
Views: 29
Size:  48.9 KB

Then you'll see the metal cover

Name:  cover.jpg
Views: 31
Size:  72.3 KB

Here is with both panels removed, the wire we will be cutting is in the yellow insulation.

Name:  nopanel.jpg
Views: 32
Size:  84.6 KB

This is the connector the wire is coming from, we are cutting the black/pink wire.

Name:  connector.jpg
Views: 30
Size:  61.0 KB

Now make sure to cover both bare ends of the wire, I chose to use female ends so I can add a switch.

Name:  cut-wires.jpg
Views: 26
Size:  58.1 KB

And the switch I used, just one I had in my garage.

Name:  switch.jpg
Views: 24
Size:  49.9 KB

And my new toolbox, I love it

Name:  toolbox.jpg
Views: 26
Size:  138.3 KB

Any questions or if I left something out feel free to ask!
Reply With Quote
  #2
Old 12-28-2008
V8 Level II's Avatar
RF Veteran
iTrader: (4)

Join Date: Nov 2004
Location: Michigan
Posts: 7,833
Good write up, Trent.

For anyone interested, here's a variation on the same idea. It's a self resetting, pushbutton dinger disabler:

2001~2003:
https://www.ranger-forums.com/forum2...84&postcount=1





2004~2006:
https://www.ranger-forums.com/forum2...8&postcount=22


Last edited by V8 Level II; 12-28-2008 at 12:07 PM.
Reply With Quote
  #3
Old 07-05-2012
Member
iTrader: (1)

Join Date: Nov 2011
Location: Copper Cliff, Ontario
Posts: 112
tried this on my 2007 sport supercab..... didn't work. i double checked that i had the right wire.

So to sovle the dinnger problem, i popped the actual buzzer off the cluster pcb..... always silent now.
Reply With Quote
  #4
Old 07-06-2012
Member

Join Date: Apr 2010
Location: Canada
Posts: 150
When I looked at doing auto windows the wiring color changed for 2007+. Might also be different for this
Reply With Quote
  #5
Old 07-06-2012
vista4.0's Avatar
Member
iTrader: (3)

Join Date: Jan 2009
Location: Beaver Falls, PA
Posts: 2,824
just to clarify. 04-06 and 07+ have different wiring. this mod is only good for 04-06
Reply With Quote
  #6
Old 07-06-2012
Member
iTrader: (1)

Join Date: Nov 2011
Location: Copper Cliff, Ontario
Posts: 112
yeah I do believe this very same black/pink wire has something to do with the dome light in my 07, because I now have no dome light... gotta connect it back together now..
Reply With Quote
  #7
Old 08-11-2013
mudlight09's Avatar
Member

Join Date: Aug 2013
Location: anniston, al
Posts: 22
I have a 95 and i the wire for my dinger runs to my door with the speaker wires. I cut the wire there and the problem was solved for about a week. But now everytime i crank the truck i hear a new ding. it does 5 sets of 5 beeps when u crank it and every 40 minutes that the truck is running. Does anybody know whats going on?
Reply With Quote
  #8
Old 08-17-2013
V8 Level II's Avatar
RF Veteran
iTrader: (4)

Join Date: Nov 2004
Location: Michigan
Posts: 7,833
Quote:
Originally Posted by mudlight09 View Post
I have a 95 and i the wire for my dinger runs to my door with the speaker wires. I cut the wire there and the problem was solved for about a week. But now everytime i crank the truck i hear a new ding. it does 5 sets of 5 beeps when u crank it and every 40 minutes that the truck is running. Does anybody know whats going on?
The 5x5 beep is the backup for the Supplemental Restraint System (airbag) lamp. It means that the SRS lamp circuit has higher than expected resistance - usually due to a burned out or missing bulb.
Reply With Quote
