extra lights
#1
extra lights
i'm thinking of adding some driving lights or something to increase the amount of light, the only problem is i dont know what to do. one option i have come up with is get hella ff50's and mount them behind the grille. but i don't know much about lighting so i need some opinions
#4
i have 5 hella 500/500fs on a custom light rack and they are awesome! im thinking about doing the 100w bulbs like 01RangerEdge did which should be diesle
if you dont use your tow hooks it would be cool to see you put them in the gap of your bumper and lower plastic or behind your grill it will keep it lookin clean
if you dont use your tow hooks it would be cool to see you put them in the gap of your bumper and lower plastic or behind your grill it will keep it lookin clean
#5
Old Guy User…
iTrader: (12)
No pics but plan is six KC Slim Light on the new front bumper.
Two Fogs mounted low
Two spots in the middle of the truck
Two Flood mounted on the outside for fill lighting.
Just remember if the lights come with 50 watt bulbs make sure the wiring is up to the task IF you increase the wattage of the bulbs.
Also OEM wiring is setup for 35 watts/per light MAX, use the OEM wiring to activate the new relays only.
Run new fused wires from the battery to the relays to the lights, to make sure the lights are getting enough amperage and no fire hazard.
Two Fogs mounted low
Two spots in the middle of the truck
Two Flood mounted on the outside for fill lighting.
Just remember if the lights come with 50 watt bulbs make sure the wiring is up to the task IF you increase the wattage of the bulbs.
Also OEM wiring is setup for 35 watts/per light MAX, use the OEM wiring to activate the new relays only.
Run new fused wires from the battery to the relays to the lights, to make sure the lights are getting enough amperage and no fire hazard.
#6
#7
I'll be going with some Hella's here in the future but I picked these guys (the blue driving lights under the bumper) up at WalMart on sale for $12.
They stay under water most of the time in the woods, they come with 55W bulbs, a wiring harness and light up switch, but me being how I am with my electronics, I used all my own stuff to hook them up. They are brighter than my stock sealed beams with the bright lights on.
Most off the shelf kits you get from WalMart or the local auto parts store will be pretty much fool proof. It would be extremely hard to mess up the wiring on this particular kit.
For the price they're hella good, I was shocked at how much light they emit. I'm gonna pick up some brighter bulbs, when I get rid of the sealed beams and get HID's, but they're more than enough as is.
They stay under water most of the time in the woods, they come with 55W bulbs, a wiring harness and light up switch, but me being how I am with my electronics, I used all my own stuff to hook them up. They are brighter than my stock sealed beams with the bright lights on.
Most off the shelf kits you get from WalMart or the local auto parts store will be pretty much fool proof. It would be extremely hard to mess up the wiring on this particular kit.
For the price they're hella good, I was shocked at how much light they emit. I'm gonna pick up some brighter bulbs, when I get rid of the sealed beams and get HID's, but they're more than enough as is.
#13
http://img232.imageshack.us/i/img0517z.jpg/
i don't know how to post pics but heres a link to a pic of the front, my plan was to install the 2 hella ff50's behind the grille, have seen it before and thought it was kinda nice
i don't know how to post pics but heres a link to a pic of the front, my plan was to install the 2 hella ff50's behind the grille, have seen it before and thought it was kinda nice
#16
Old Guy User…
iTrader: (12)
http://img232.imageshack.us/i/img0517z.jpg/
i don't know how to post pics but heres a link to a pic of the front, my plan was to install the 2 hella ff50's behind the grille, have seen it before and thought it was kinda nice
i don't know how to post pics but heres a link to a pic of the front, my plan was to install the 2 hella ff50's behind the grille, have seen it before and thought it was kinda nice
The grille in this year Ranger will block a lot of the light.
When installed behind the grille on an 03 or earlier they shine through OK.
IMHO… mount a set of thin light on the bumper, next to the drop n the bumper.
Last edited by Scrambler82; 01-28-2011 at 07:36 AM. Reason: spl chk
