  #51
Old 08-04-2008
robert99ranger's Avatar
RF Veteran
Thread Starter
iTrader: (4)

Join Date: Aug 2007
Location: Indiana/Mississippi
Posts: 5,807
Ya, I couldn't believe that the junkyard I go to is open everyday from 8-6ish. It is really nice at 8:30 in the morning on Sunday when you are in a junkyard, hearing the birds churping, no one else around, and the smell of old gas in the air. That is the time I will go from now on. They have like 1800 cars and change them out daily.
Reply With Quote
  #52
Old 08-04-2008
Fx4wannabe01's Avatar
RF Veteran
iTrader: (23)

Join Date: May 2005
Location: Boring, Oregon
Posts: 21,721
Can't forget that junkyard car funk in the air....



any rangers out there?
Reply With Quote
  #53
Old 08-05-2008
Silver's Avatar
Member

Join Date: Jun 2006
Location: edenton,nc
Posts: 2,708
ya my truck is 2wd but the black cluster i took out was for a 4wd just never noticed it till it was out
Reply With Quote
  #54
Old 08-05-2008
RaNgErbRo's Avatar
Member

Join Date: Apr 2008
Location: Monrovia,Cali
Posts: 14
what white one would word on my 01 edge i really like your set up with the blue led how did you do that let me know thanks
Reply With Quote
  #55
Old 08-05-2008
robert99ranger's Avatar
RF Veteran
Thread Starter
iTrader: (4)

Join Date: Aug 2007
Location: Indiana/Mississippi
Posts: 5,807
There is hardly no Rangers at my junkyard expect for like 2-3. They are so screwed up that you couldn't get a part off them. Saw one sport trac that the hood folded up like an acordian on. Then there is like 20 Explorers.
Reply With Quote
  #56
Old 08-05-2008
Fx4wannabe01's Avatar
RF Veteran
iTrader: (23)

Join Date: May 2005
Location: Boring, Oregon
Posts: 21,721
Quote:
Originally Posted by RaNgErbRo View Post
what white one would word on my 01 edge i really like your set up with the blue led how did you do that let me know thanks
Linky: https://www.ranger-forums.com/forum2...ad.php?t=62796

That's my cluster build thread. I had a buddy do it for me...i had no time to do it myself. I did all the switches though.

That thread should have all the info you need....even if you don't wanna do LED's in the cluster, the same thread applies to changing the color of the cluster(paint).


You can use 01 and older Explorer, 05ish(idk) and older Explorer Sport and Explorer Sport Trac clusters to get the white faced like mine and the original posters. simple plug and play...it'll all work. Silver faced is a '03 model year ranger exclusive...you can find those and they'll work as well.
Reply With Quote
  #57
Old 2 Days Ago
Member

Join Date: Dec 2017
Location: Wooster, Ohio
Posts: 3
Hey all, I have two questions if you would be so kind.
1st, what is that small board/chip in the top driver side corner of the cluster? Is that something i should swap if i change out the cluster?
2nd, i picked up a white face cluster really cheap and was really excited to get it but noticed that it doesn't have the 4x4 and 4x4 low lights on the front. The holes are in the back but light can't get through. Is there a quick way to fix that or is the cluster a loss if i want those lights?
Reply With Quote
  #58
Old 2 Days Ago
mhoward's Avatar
Member

Join Date: Aug 2015
Location: Evansville, Indiana
Posts: 580
No way to make that work. You need to find another 4x4 white face cluster. As for the chip, not sure what it is for, but I have swapped out clusters a few times and never changed it.
Reply With Quote
  #59
Old 2 Days Ago
Member

Join Date: Dec 2017
Location: Wooster, Ohio
Posts: 3
Quote:
Originally Posted by mhoward View Post
No way to make that work. You need to find another 4x4 white face cluster. As for the chip, not sure what it is for, but I have swapped out clusters a few times and never changed it.
Ok, could I still use it if im not worried about the 4x4 lights for the time being or will that prevent the system from working properly?
Reply With Quote
  #60
Old 2 Days Ago
mhoward's Avatar
Member

Join Date: Aug 2015
Location: Evansville, Indiana
Posts: 580
As far as I know, that won't cause a problem with the 4x4 operation, you simply won't have the indicator lights. Should be able to determine what you're in based on the position of the 4x4 switch.
Reply With Quote
  #61
Old 1 Day Ago
Member

Join Date: Dec 2017
Location: Wooster, Ohio
Posts: 3
Ok thank you, Ill still probably keep an eye out for a replacement since I really don't want to forget that it is in 4x4 and chew up the joints and t-case while on the road, but it will work for now
Reply With Quote
  #62
Old 1 Day Ago
mhoward's Avatar
Member

Join Date: Aug 2015
Location: Evansville, Indiana
Posts: 580
Yep, but for the short haul, your 4x2 cluster should be fine. You probably can sell the 4x2 cluster later and get your $$ back. :)
Reply With Quote
