The Best Way To Lift The Rear??????

whats the best way to lift the rear of my truck


I am thinking of leveling my truck and dont know what way to go. I had blocks on my last truck but dont know if that is the best way. I dont want to have axle wrap.

I saw thas some people have used lowering shackles to lift the rear, is that a good way to lift it??
Reply With Quote
  #2
Old 09-21-2009
My91Ranger's Avatar
Member
iTrader: (1)

Join Date: Apr 2007
Location: Roseville, Michigan
Posts: 2,252
The best method is lift springs. Replace the entire leaf pack with a new one. Not a popular method because of cost. Blocks, add-a-leafs are shackles are the most common methods because they are cheap and easy.
Reply With Quote
  #3
Old 09-21-2009
sullys_ranger's Avatar
Member

Join Date: Mar 2006
Location: NewLexington, Ohio
Posts: 3,615
love my aals
Reply With Quote
  #4
Old 09-21-2009
The S-10 Killer's Avatar
Member

Join Date: Aug 2008
Location: BR, LA
Posts: 646
the belltech 6400's add lift about 1.25-1.5 of lift...but what do you have right now and how much you looking to put on to level it out???

sick truck as always
Reply With Quote
  #5
Old 09-21-2009
Blackonblackfx4's Avatar
Member
iTrader: (1)

Join Date: Jan 2009
Location: Edmonton, Alberta
Posts: 914
Bigger Blocks
Reply With Quote
  #6
Old 09-21-2009
S10Killer's Avatar
Member
Thread Starter

Join Date: Apr 2008
Location: SO CAL
Posts: 381
Quote:
Originally Posted by The S-10 Killer View Post
the belltech 6400's add lift about 1.25-1.5 of lift...but what do you have right now and how much you looking to put on to level it out???

sick truck as always
its all stock!!!
I love the look of it but i want it to sit even . thanks


Quote:
Originally Posted by Blackonblackfx4 View Post
Bigger Blocks
biger blocks ?? wont that cause more axle wrap
Reply With Quote
  #7
Old 09-22-2009
The S-10 Killer's Avatar
Member

Join Date: Aug 2008
Location: BR, LA
Posts: 646
well whats the difference in measurement from body line to ground above the front and rear tires?
Reply With Quote
  #8
Old 09-22-2009
S10Killer's Avatar
Member
Thread Starter

Join Date: Apr 2008
Location: SO CAL
Posts: 381
a good 3 to 4 inches i think . you can see how raked it is here
Name:  100_0568.jpg
Views: 21
Size:  54.6 KB

Last edited by S10Killer; 09-22-2009 at 04:49 PM.
Reply With Quote
  #9
Old 09-22-2009
Woods-Rider's Avatar
Member
iTrader: (2)

Join Date: Apr 2008
Location: Hillsboro, OR
Posts: 1,108
chevy half ton springs from a JY and belltech 6400 shackles. it will give you about 4" of lift, a better ride, more flex, and costs under $100.
Reply With Quote
  #10
Old 09-22-2009
RangerJustin's Avatar
Member
iTrader: (1)

Join Date: Feb 2005
Location: SoCal
Posts: 4,428
the half tons require new mounting of the front hanger correct?
Reply With Quote
  #11
Old 09-22-2009
The S-10 Killer's Avatar
Member

Join Date: Aug 2008
Location: BR, LA
Posts: 646
Reply With Quote
  #12
Old 10-08-2009
HillPrideRanger's Avatar
Member

Join Date: Mar 2009
Location: Aurora, Colorado
Posts: 442
Quote:
Originally Posted by RangerJustin View Post
the half tons require new mounting of the front hanger correct?
you just have to flip the rear mount (the one that mounts to the shackles)
Reply With Quote
  #13
Old 10-08-2009
Woods-Rider's Avatar
Member
iTrader: (2)

Join Date: Apr 2008
Location: Hillsboro, OR
Posts: 1,108
no, you have to move the front hangers 6" forward on the frame. not that hard. took me about 6 hours total.
Reply With Quote
  #14
Old 10-08-2009
Downey's Avatar
RF Veteran
iTrader: (1)

Join Date: Oct 2007
Location: Muncy, PA
Posts: 8,470
or you could get explorer leaf springs and shackles i got 3 inches of lift from my explorer leaf springs
Reply With Quote
  #15
Old 10-08-2009
Johnbaum13's Avatar
Member
iTrader: (1)

Join Date: Jan 2008
Location: Dallas, TX
Posts: 2,343
or just use a jack!
Reply With Quote
  #16
Old 10-08-2009
KLC's Avatar
KLC KLC is offline
RF Veteran
iTrader: (29)

Join Date: Nov 2007
Location: New Mexico
Posts: 13,115
Quote:
Originally Posted by My91Ranger View Post
The best method is lift springs. Replace the entire leaf pack with a new one. Not a popular method because of cost. Blocks, add-a-leafs are shackles are the most common methods because they are cheap and easy.
I agree, the best way is lift leaf springs.
Reply With Quote
  #17
Old 10-13-2009
backwoodsmudders's Avatar
Member

Join Date: Oct 2009
Location: Hartford, WI
Posts: 57
I dont recommend getting add-a-leafs. Did it to mine and they said I would get about 1-1.5'' of lift but I got more in the area of 3-4'' of lift. I had to get some new torsion keys because the front was already cranked down and it was squatting badly in the front. Even still I have to put sand bags in the rear just to keep it down...The easiest and cheapest would be to get a set of blocks and new U-bolts. Takes 15 minutes to do.
Reply With Quote
  #18
Old 10-13-2009
Downey's Avatar
RF Veteran
iTrader: (1)

Join Date: Oct 2007
Location: Muncy, PA
Posts: 8,470
Quote:
Originally Posted by Blackonblackfx4 View Post
Bigger Blocks
Quote:
Originally Posted by backwoodsmudders View Post
I dont recommend getting add-a-leafs. Did it to mine and they said I would get about 1-1.5'' of lift but I got more in the area of 3-4'' of lift. I had to get some new torsion keys because the front was already cranked down and it was squatting badly in the front. Even still I have to put sand bags in the rear just to keep it down...The easiest and cheapest would be to get a set of blocks and new U-bolts. Takes 15 minutes to do.
Ok IMO bigger blocks is the worst and most unsafe idea out there. IMO you should never stock blocks on top of blocks or put in a block that is like 5 inch tall. bigger blocks will give you more axle wrap and i have seen those taller blocks roll around turns and the ubolts bend and make it not drive able. so plz stop saying getting bigger blocks its a cheap unsafe cop out IMO.


back on subject i think if you found some explorer leaf springs and shackles you should level out your truck very easy and for pretty cheap.
Reply With Quote
  #19
Old 10-13-2009
04blackedge's Avatar
RF Veteran
iTrader: (13)

Join Date: Jan 2007
Location: Durham, NC
Posts: 23,426
As long as you use steel blocks and not aluminum theres nothing wrong with stacking them. Its not like a Ranger makes enough power to twist the axle out anyway.
Reply With Quote
  #20
Old 03-01-2010
cawalther's Avatar
Member
iTrader: (3)

Join Date: Feb 2010
Location: Lynchburg, VA
Posts: 219
idk...I don't think I would trust two pieces of metal just sitting together no matter how tight you can get those ubolts. Unless I had them welded together I wouldn't trust them. and they do break regardless of what they're made of. And those U-bolts can only handle so much, so again...probably not the best idea

For raising my rear I'm looking at going with explorer leaf springs (from a junk yard) and/or shackles. That seems to be an extremely easy way and not too hard on the wallet. I'm still trying to figure out which rating sportrac explorer leaf springs to get though. car-part.com has 7 ratings for their leafsprings to pick from. the codes they have are: 1, 2, 3, U, H, F and L. I am still leaving open the option of an AAL.

but Lucas, since youve got the prerunner look, you may want to go with that spring swap and shackle flip. you should check around for just the spring swap if you only want lift and don't need the extra wheel travel.
Reply With Quote
  #21
Old 03-02-2010
morris's Avatar
RF Veteran
iTrader: (5)

Join Date: Feb 2008
Location: South Detroit.
Posts: 7,833
i'm guessing that the 1 code is gonna be the same for the keys, it's used for the towing package. i realize that your truck is older and i'm just taking a guess on 1 being the stiffest and 3 not so much. as for U,H,F,L i got nothing.

lets see if one of the experienced guys will chime in about this.
Reply With Quote
