Ultra-Gauge Support/Ordering Thread

Name:  UG.jpg
Views: 69
Size:  3.3 KB

I figured with everyone buying an Ultra-Gauge these days, I'd start a Support thread for anyone needing help or links to help or ordering. I have contacted Ultra-Gauge and they love the idea. They said that they just dont have time or resources to stay on all car/truck forums.

Also on a side note, Ultra-Gauge informed me of discounts that may be offered to MASS ORDERS. here is what they told me:

Quote:
Originally Posted by Ultra-Gauge
Thank you for your message and your support on the Ranger forums.
If I understand correctly, you would like someone at UG to become an active member on the ranger forums to answer questions and point users to information on the UG site?
We have done this on other sites. However we did so to limit the spread of misinformation that we had become aware of. I suspect it was begun by our competition masquerading as a user.
While we could provide such support our available bandwidth is limited and I'm not sure that we could keep up with the posts.
If you are willing to do it for us, we would be appreciative.
Also, in the past we have offered group discounts to forums. For example, a particular Toyota forum purchased more than 150 units. Essentially we announced a procedure and window of time for forum members to place an order. After the window had expired, all the validated members received a refund equal to the discount level the forum had achieved. For it to work, we had a volunteer on the Toyota forum that championed the whole offer.
Once I find out what the tier levels are for the discounts, I will update this thread. Then for all those interested, we can get an RF order together later.

RESOURCES

-WEBSITE: UltraGauge Automotive Information Center and OBDII Scan Tool

-Ordering Page: ORDER HERE

- Ultra-Gauge Forum: CLICK HERE

-Direct Support: [email protected]
UltraGauge Support

-Owner's Manual: CLICK HERE


What is the Ultra-Gauge?

Many of you may read the title and wonder what an Ultra-Gauge is. The UG (What we will call it for short) is a scan tool for any vehicle with OBD-II diagnostics. It mounts in your car/truck and plugs into the OBD-II port under the dash. It actively scans the vehicle using the same sensors that the computer reads and displays that information on the LCD screen.

The UG has a total of 74 Gauges it can display. However, for the Ford Ranger, these are limited due to the sensors our trucks have. They are listed below. These gauges will displayed 6 per page on a total of three pages. So basically, you have the option of choosing up to 18 gauges to display. The pages on the UG can be set to Auto-Advance to "X" number of seconds or you can have it to a fixed screen.

One powerful tool of the Ultra-Gauge is its capabilities to Read and Clear Trouble Codes!!! It is one of the cheapest OBD-II diagnostic tools on the market. You will easily pay more than $100 for one at Advance Auto or AutoZone.

Also, the UG has Max and Min alarms that can be set for each gauge. So say if you have the engine temp max gauge at 205*F like me, and it hits that threshold, it will make an alarm. Alarmas can be suspended or turned off. Also I will provide my alarm setting tonight.

WHAT DOES THE ULTRA-GAUGE LOOK LIKE?

the UG is a nice thin compact unit. There are three buttons on the back (Menu, Up, Down) It is smaller than a cell phone. It has a nice crisp LCD blue display.

Name:  2010-12-25102200-1-1.jpg
Views: 103
Size:  44.7 KB

HOW DOES THE ULTRA-GAUGE MOUNT?

The UG mounts using a suction cup mount with a bendable "arm" that connects to the unit. UG.com recommends putting it in lower-left corner of window right above dash. However, for the Ford Ranger, I personally recommend placing it as far top-left of the window as possible. It will require some bending of the mounting arm into a squished "S" shape, but it can be done.

Name:  2010-12-28125458-1.jpg
Views: 70
Size:  36.9 KB
(This was before hiding the wire)

I also recommend Hiding the wire behind the A-Pillar Plastic.

Name:  2010-12-28211813-1.jpg
Views: 71
Size:  33.9 KB

Name:  2010-12-28211802.jpg
Views: 69
Size:  34.4 KB

WHAT COMES IN THE BOX?

The UG comes with the unit and mount




WHAT ARE THE DIMENSIONS OF THE ULTRA-GAUGE?





WHAT GAUGES ARE DISPLAYED?

Here are the Gauges for the Ranger (give or take)

* Open/Closed Loop Emissions Status
* Percent Engine Load
* Engine coolant temperature
* Short Term Fuel Trim Bank 1
* Long Term Fuel Trim Bank 1
* Short Term Fuel Trim Bank 2
* Long Term Fuel Trim Bank 2
* RPM
* MPH
* Ignition Timing Advance
* Intake Air Temperature
* Mass Air Flow Sensor output in grams/sec
* Absolute Throttle Position Percentage
* Bank 1 Oxygen Sensor 1 Voltage
* Bank 1 Oxygen Sensor 2 Voltage
* Bank 2 Oxygen Sensor 1 Voltage
* Bank 2 Oxygen Sensor 2 Voltage
* Distance traveled with Check Engine Light on
* Mass Air Flow 2, Calibrated/Calculated
* Instantaneous Miles Per Gallon (MPG)
* Average Miles Per Gallon (MPG)
* Average Miles Per Hour (MPH)
* Average Gallon Per Hour (GPH) - general
* Run Time - general
* Distance - general
* Fuel Used - general
* Intantaneous Gallons Per Hour (GPH)
* Fuel Tank Gallons Remaining
* Distance to Empty(DTE)
* Time to Empty (TTE)
* Average MPH - trip
* Average MPG - trip
* Fuel Used Gallons- trip
* Average Gallon Per Hour (GPH) - trip
* Run Time -trip
* Distance - trip
* Oil Distance
* Service Distance
* UltraGauge Temperature

Like mentioned above, the Gauges are displayed on three pages in "slots." Each slot is assigned a letter like so:



My layout is (I will fill out tonight, I cant remember them all):
  • A-MPH
  • B-RPM
  • C-ENGINE COOLANT TEMP.
  • D-INTAKE AIR TEMP
  • E-AVG MPH
  • F-Distance till empty
  • G-Inst. MPG
  • H-AVG. MPH
  • I-INST Gal./HR
  • J-AVG Gal./HR
  • K-
  • L-Time till empty
  • M-Service Oil
  • N-Service Distance (I use to keep track of tire rotation)
  • O-
  • P-
  • Q-
  • R-

WHAT KIND OF CALIBRATION IS INVOLVED?

With the Ford Ranger, there is no fuel sensor (to my knowledge). We have a float attached to a sending unit that measures based on height of fuel in the tank. SOOOOO the UG has to be calibrated. You have two calibrations you can perform. One is distance and the other MPGs.

HOW TO CALIBRATE<CLICK


This should give you a basic understanding of the Ultra-Gauge. If you have any questions, please feel free to contact me or post in this thread.

DIFFERENT COLOR DISPLAY

One tip for people that already have the Ultra-Gauge:

To change color of display, cut a piece of colored cellophane and place it on the screen. just make it a little bigger than the screen and wedge it in there:



here is where one user used green cellophane:



Also here are some other thread of interest within RF:

https://www.ranger-forums.com/f18/gr...e-pics-117760/

https://www.ranger-forums.com/f41/my...-gauge-117105/

https://www.ranger-forums.com/f25/re...agauge-115742/

https://www.ranger-forums.com/f18/ul...ngauge-111012/

if your down for one, just go to the ordering page, you dont have to wait. I dont have any info on a group buy yet(costs per unit). I have sent admin an email at ultra-Gauge today and am waiting to hear back.

----------

Last edited by dixie_boysles; 01-25-2011 at 10:04 AM.
Reply With Quote
  #2
Old 01-25-2011
04blackedge's Avatar
RF Veteran
iTrader: (13)

Join Date: Jan 2007
Location: Durham, NC
Posts: 23,426
Great work Scott
Reply With Quote
  #3
Old 01-25-2011
dixie_boysles's Avatar
Member
Thread Starter
iTrader: (1)

Join Date: Jul 2006
Location: NC
Posts: 3,778
thanks! figured it would be beneficial. and like I said, if we have one huge group order than we may be able to get a discount. I dont know tier levels yet though as far as how many you have to have sign up and pay to get the discounts
Reply With Quote
  #4
Old 01-25-2011
95lorange's Avatar
Member

Join Date: Mar 2009
Location: Hurt, VA
Posts: 54
Depending on the prices, I would be interested in one.
Reply With Quote
  #5
Old 01-25-2011
zak873's Avatar
Member
iTrader: (1)

Join Date: Jul 2010
Location: southcarolina
Posts: 1,108
I'm down. been wanting to order one, but I can hold off till its figured out.
Reply With Quote
  #6
Old 01-25-2011
dixie_boysles's Avatar
Member
Thread Starter
iTrader: (1)

Join Date: Jul 2006
Location: NC
Posts: 3,778
well I can tell you that they are $76 shipped to your door at regular price. so cheaper than that. but you will be waiting a while for a group order. I can get one together if its ok with admins and mods though
Reply With Quote
  #7
Old 01-25-2011
SVT01RANGER's Avatar
Member
iTrader: (2)

Join Date: Jun 2004
Location: West Eugene, OR
Posts: 3,634
great write up scott, i have had mine from the start, great product, still trying to get it dialed in, got the speed down, and now all i need to work on is the MPG
Reply With Quote
  #8
Old 01-25-2011
TrePaul86's Avatar
Member
iTrader: (8)

Join Date: Apr 2007
Location: Gresham, OR
Posts: 1,369
The MPG calibration is easy Rob... Fill up, hit zero MPG categories, drive i'd say 1/2-3/4 tank worth... Fill up. Go into calibration and set your MPG calibration to the number of gallons you got on fill up. This will change your calibration, from what it was reading to what you put in it. Make sure you have the exact fuel tank size set.
Reply With Quote
  #9
Old 01-25-2011
01RangerEdge's Avatar
Scrambles the DeathDealer
iTrader: (11)

Join Date: Jul 2009
Location: Jackson, MO
Posts: 7,598
My manual says 19.5 gallon tank. I ran it till the low fuel light came on. Filled up and only got 16.7 gallons in it.

So I don't really know what the tank size should be. I changed it to 18 gallons. Now the DTE and fuel level are almost agreeing with the dash gauge.
Reply With Quote
  #10
Old 01-25-2011
TrePaul86's Avatar
Member
iTrader: (8)

Join Date: Apr 2007
Location: Gresham, OR
Posts: 1,369
Yeah, I set mine to 16.7... I've never put more than 16.7 gallons in my truck.. EVER. Though Shane swears I have the 19.xx gallon tank. I guess, it really doesn't matter what you set the tank to. If you never go below 16.7 gallons, it's like that's your 0 point.
Reply With Quote
  #11
Old 01-25-2011
Taylor's Avatar
Ive been dubbed....an old volk
iTrader: (18)

Join Date: Mar 2010
Location: Nashville, NC
Posts: 7,110
Nice work Scott! Another NC'er ftw. lol.

How are you liking your scanguage? Is there anything you would change about it?
Reply With Quote
  #12
Old 01-25-2011
01RangerEdge's Avatar
Scrambles the DeathDealer
iTrader: (11)

Join Date: Jul 2009
Location: Jackson, MO
Posts: 7,598
Quote:
Originally Posted by Taylor View Post
How are you liking your scanguage? Is there anything you would change about it?
uh wut?
Reply With Quote
  #13
Old 01-25-2011
TrePaul86's Avatar
Member
iTrader: (8)

Join Date: Apr 2007
Location: Gresham, OR
Posts: 1,369
Wirelessly posted (Droid X)

Wrong thread bud.

This is an Ultra-Gauge thread.... Not a ScanGauge thread.
Reply With Quote
  #14
Old 01-25-2011
SteelDirigible's Avatar
Member
iTrader: (4)

Join Date: May 2010
Location: Lexington, KY
Posts: 3,666
they are $60 on their site right now... with a mail in rebate.... i should buy one.
Reply With Quote
  #15
Old 01-25-2011
StxDangerRanger's Avatar
RF Veteran
iTrader: (2)

Join Date: Dec 2010
Location: Flat Rock, Mi
Posts: 6,313
I would absolutely love to have one of these. but i'm not OBD2. i'm thinking of downgrading in the future to a 4cyl so i could get some better MPGS goin to school. so hopefully then i'll be able to get one.
Reply With Quote
  #16
Old 01-25-2011
SteelDirigible's Avatar
Member
iTrader: (4)

Join Date: May 2010
Location: Lexington, KY
Posts: 3,666
so does this clip into the mount thing (that attaches to the suction part)?

basically, could i screw the mount plate into my dash somewhere, and just pop the ultra gauge on or off as i please? i'd like that over the suction cup install.
Reply With Quote
  #17
Old 01-25-2011
TrePaul86's Avatar
Member
iTrader: (8)

Join Date: Apr 2007
Location: Gresham, OR
Posts: 1,369
No, it's only mount is with the suction cup. It does however clip in and out of that easily. Only thing is, you wouldn't want to take it in and out often... Unless you don't mind the wires hanging out since it has to always be plugged into your OBDII port.
Reply With Quote
  #18
Old 01-25-2011
dixie_boysles's Avatar
Member
Thread Starter
iTrader: (1)

Join Date: Jul 2006
Location: NC
Posts: 3,778
That is the omly problem. The power wiredis hard wired into the device. So if uou plan on permanatly installing it its there to stay. No taking it off unless u remove the whole unit. But I have no need to so im good.

I'm sure UG will eventually come out with a removable one but until then ur stuck. That's where the price and features come it. All of its features and price outweigh that problem
Reply With Quote
  #19
Old 01-25-2011
SteelDirigible's Avatar
Member
iTrader: (4)

Join Date: May 2010
Location: Lexington, KY
Posts: 3,666
i bet i could...
Reply With Quote
  #20
Old 01-25-2011
TrePaul86's Avatar
Member
iTrader: (8)

Join Date: Apr 2007
Location: Gresham, OR
Posts: 1,369
I would have to agree Scott.

I calibrated my MPH today using my GPS to track me somewhere, then went in and adjusted how far I went according to my GPS vs. what the computer thinks I traveled.

Just filled up tonight, reset my tank to full in the fuel menu, and after about 1/2 tank I'm going to fill up again and go into the Calibration for MPG and adjust how many gallons I added at the pump vs. how many gallons the computer thinks I used since the "zero".
Reply With Quote
  #21
Old 01-25-2011
TrePaul86's Avatar
Member
iTrader: (8)

Join Date: Apr 2007
Location: Gresham, OR
Posts: 1,369
Quote:
Originally Posted by SteelDirigible View Post
i bet i could...
Only way you're going to get it to screw to the dash is if you made your own mount for it. But the UG one is nice because it's flexible enough to fit in almost any position you want it to, allows for movement of the screen once it's in the mount, and allows for full access to the buttons on the back of the unit.
Reply With Quote
  #22
Old 01-25-2011
SteelDirigible's Avatar
Member
iTrader: (4)

Join Date: May 2010
Location: Lexington, KY
Posts: 3,666
i just ordered mine. so we'll see what i work out.
Reply With Quote
  #23
Old 01-25-2011
TrePaul86's Avatar
Member
iTrader: (8)

Join Date: Apr 2007
Location: Gresham, OR
Posts: 1,369
Don't be surprised when you get it that it's small as heck. From the pics Scott posted at first, I thought it was a large LCD display. It's not, but everything is really easy to ride ignoring the size.

I'll be waiting on that mount..
Reply With Quote
  #24
Old 01-26-2011
dixie_boysles's Avatar
Member
Thread Starter
iTrader: (1)

Join Date: Jul 2006
Location: NC
Posts: 3,778
yet its still bigger than the Scangauge. I was surprised too Trevor, but its the perfect size for me. I think any bigger it would be a hindrance (thats what she said...lol) Just by posting this thread and a few more regarding the UG, i should be paid commission lol!! i know of at least 10 people that have bought one after seeing the UG threads (im one of them)
Reply With Quote
  #25
Old 01-26-2011
SVT01RANGER's Avatar
Member
iTrader: (2)

Join Date: Jun 2004
Location: West Eugene, OR
Posts: 3,634
well it maybe bigger then the scangauge, but it is alot thinner then the SG
Reply With Quote
Reply

Related Topics
Thread Thread Starter Forum Replies Last Post
My New Ultra-Gauge dixie_boysles Audio & Video Tech 94 04-28-2011 08:35 PM
Ultra gauge problem newfrank Audio & Video Tech 3 03-17-2011 01:49 PM
ultra gauge... cheaper then scangauge SVT01RANGER General Technical & Electrical 114 08-29-2010 11:38 AM
Ultra Gauge meets Air Freshener t5cents Interior Semi-Tech 21 08-28-2010 07:05 PM


Thread Tools Search this Thread
Search this Thread:

Advanced Search

Posting Rules
You may not post new threads
You may not post replies
You may not post attachments
You may not edit your posts

BB code is On
Smilies are On
[IMG] code is On
HTML code is Off
Trackbacks are Off
Pingbacks are Off
Refbacks are Off



All times are GMT -6. The time now is 01:36 AM.


We are a participant in the Amazon Services LLC Associates Program, an affiliate advertising program designed to provide a means for us to earn fees by linking to Amazon.com and affiliated sites.
